Pull type double shafts paddle mixer
TDWK no gravity open type mixer is also called pulling type paddle mixer. On the basis of
long-term practice in the field of mixer, this series machine overcomes the drawback of
horizontal mixer to clean up inconveniently. The gear reducer and mixer rotor are direct
transmission, higher reliability and longer service life. It is used for mixing powder and
powder, granule and granule, granule and powder, and adding a bit liquid. It is wide
application in food, chemical, pesticide, feeding stuff and battery etc.
(1). High efficiency：Rotate reversely and throw materials to different angles, mixing time only 1-3 minutes.
(2). High uniformity：Compact design and rotated shafts be filled with hopper, mixing uniformity up to 99%.
(3). Low residue：There is only 2-5mm gap between paddles & wall,open-type discharge outlet.
(4). W/O leakage：Patent design & ensure the rotating axle & discharge outlet w/o leakage.
(5). Full clean：Full weld and polishing process for mixing hopper, w/o any fastening piece like screw, nut.
(6). Elegant appearance: The whole machine is from full stainless steel to make its profile elegant except gear reducer case, direct mechanism and bearing seat.
Model no. | TDWK-150 | TDWK-300 | TDWK-500 | TDWK-1000 | TDWK-1500 | TDWK-2000 | TDWK-3000 |
Effective Volume | 150L | 300L | 500L | 1000L | 1500L | 2000L | 3000L |
Rotate Speed | Customized or to be confirmed | ||||||
Total Power | Customized or to be confirmed | ||||||
Total Dimension | As per final drawing | ||||||
Power Supply | 3P AC208-415V 50/60Hz | ||||||
